Ayrton Zonda 9 FX LED Wash
Ayrton Zonda 9 FX LED Wash
In Stock and ready to ship rentals
People who were interested in this product also liked:
Details
Shipping
Details
The Zonda 9 FX is a revolutionary luminaire designed for stage lighting, powered by a high-performance 40W RGB+W LED source that can generate a potent light output of 25,000 lumens. With a proprietary optical system, which includes 37 PMMA lenses and glass light guides, it delivers a harmonious blend of pastel and vibrant colours. Its 50mm truncated transmitting lens offers a zoom ratio of 14:1, providing an expansive zoom range of 4.0° to 56°.
The unit's structure is optimised for cooling, weight reduction, and size, making it a compact and efficient lighting solution. It offers infinite continuous rotation on pan and tilt axes, individual LED control for 3D volumetric effects, and a high-definition liquid effect for advanced graphic effects.
The Zonda 9 FX is equipped with a sophisticated 4-colour RGBW mix that produces uniform light beams with rich saturated and pastel hues. It also features a flicker-free source management suitable for TV applications and all video recorded events.
Its hardware features include an integrated wireless CRMX TiMo™ RDM receiver from LumenRadio™, XLR 5 pin male and female connectors for DMX connection, and powerCON TRUE1 male connectors for power connection. The luminaire uses DMX 512 protocol, through DMX cable or wireless system, and is DMX-RDM compatible.
The Zonda 9 FX operates on an electronic supply with active PFC of 120 to 240 Volts – 50/60Hz with a maximum power consumption of 1,400 W. Its housing is built from aluminium and steel metal plates, with moulded covers made of self-extinguishing fire retardant ABS PC.
The Zonda 9 FX is a revolutionary luminaire designed for stage lighting, powered by a high-performance 40W RGB+W LED source that can generate a potent light output of 25,000 lumens. With a proprietary optical system, which includes 37 PMMA lenses and glass light guides, it delivers a harmonious blend of pastel and vibrant colours. Its 50mm truncated transmitting lens offers a zoom ratio of 14:1, providing an expansive zoom range of 4.0° to 56°.
The unit's structure is optimised for cooling, weight reduction, and size, making it a compact and efficient lighting solution. It offers infinite continuous rotation on pan and tilt axes, individual LED control for 3D volumetric effects, and a high-definition liquid effect for advanced graphic effects.
The Zonda 9 FX is equipped with a sophisticated 4-colour RGBW mix that produces uniform light beams with rich saturated and pastel hues. It also features a flicker-free source management suitable for TV applications and all video recorded events.
Its hardware features include an integrated wireless CRMX TiMo™ RDM receiver from LumenRadio™, XLR 5 pin male and female connectors for DMX connection, and powerCON TRUE1 male connectors for power connection. The luminaire uses DMX 512 protocol, through DMX cable or wireless system, and is DMX-RDM compatible.
The Zonda 9 FX operates on an electronic supply with active PFC of 120 to 240 Volts – 50/60Hz with a maximum power consumption of 1,400 W. Its housing is built from aluminium and steel metal plates, with moulded covers made of self-extinguishing fire retardant ABS PC.
Shipping
This equipment has been inspected by a Main Light certified technician at one of our locations.
Features
- High-performance 40W RGB+W LED source
- Powerful light output of 25,000 lumens
- Proprietary optical system with 37 PMMA lenses and glass light guides
- Perfectly crisp separation between light sources for improved contrast
- 50mm truncated transmitting lens with a zoom ratio of 14:1
- Wide zoom range of 4.0° to 56°
- Optimised cooling system and smart design for reduced size and weight
- Infinite continuous rotation on pan & tilt axes
- Individual LED control for 3D volumetric effects
- High-definition LiquidEffectTM for complex graphic effects
- Sophisticated 4-colour RGBW mix for uniform light beam and rich colours
- Flicker-free source management, suitable for TV applications and all video recorded events
- Integrated wireless CRMX TiMo™ RDM receiver from LumenRadio™
- Compliant with DMX 512 protocol, DMX-RDM compatible
- Local control panel with LCD display
Specifications
- Lumens: 25,000
- Zoom Aperture: 4.0° to 56°
- Frontal Lens: 37 x 50 mm
- Beam Aperture: 4.0° to 56°
- High-resolution stepper motors operated via microprocessors for smooth movements
- Total luminaire output: up to 25,000 lumens
- CRI: up to 86
- Rated Life: L70: up to 40,000 hours
- Power Supply: Electronic supply with active PFC 120 to 240 Volts – 50/60Hz
- Power Consumption: 1,400 W maximum
- Housing: Aluminium and steel metal plates, self-extinguishing fire retardant ABS PC (V0 class) covers
- Connectors: XLR 5 pin male and female connectors for DMX connection, powerCON TRUE1 male connectors for power connection
- Compliance: EU (EMC & LVD), US (Safety & EMC)
- Size: 530 x 625 x 280 mm (l x h x d)
- Weight: 29.2 kg
- Operating Positions: all (device on floor or fixed to a support)
- Maximum Permitted Ambient Temperature (Ta max): 45°C (113°F)
- Minimum Permitted Ambient Temperature (Ta min): -10°C (14°F)
- Minimum Usage Distance: 3.0 m (9.84 ft)
