RoboSpot MotionCamera

The RoboSpot MotionCamera is a revolutionary moving head fixture featuring an integrated HD camera remotely controlled via DMX to pan, tilt, zoom and autofocus.

Featuring a full HD camera with high light sensitivity capabilities down to 0.3 Lux illumination levels, the fixture provides a “first person view” for the followspot operator to track the performer across the stage. Video signals are instantly transferred to the RoboSpot BaseStation via a high-speed Ethernet cat5 cable.

Technical Specification

• CAMERA

  • Type: SNZ-6320
  • Resolution: 1920x1080, 16:9 Full HD (1080p) resolution support
  • Zoom:
    • 32x optical zoom
    • 16x digital zoom
  • Streaming: H.264, MPEG dual codec, Multiple streaming
  • Vision: Day & Night (ICR), WDR (120dB)
  • Minimum illumination: 0.3 Lux

• CONTROL AND PROGRAMMING

  • Setting & Addressing: two-row LCD display & 4 control buttons
  • Protocols: USITT DMX-512, RDM
  • Wireless CRMX™ technology from Lumen Radio (on request)
  • DMX Protocol modes: 1
  • Control channels: 8
  • Pan/Tilt resolution: 16 bit
  • Zoom: 8 bit

• MOVEMENT

  • Tilt movement: 270°
  • Pan movement: 540°
  • Movement control: Standard and Speed
  • Automatic Pan/Tilt position correction

• THERMAL SPECIFICATION

  • Maximum ambient temperature: 45°C (113°F)
  • Maximum surface temperature: 55°C (131°F)
  • Minimum operating temperature: -5°C (23°F)

• ELECTRICAL SPECIFICATION AND CONNECTIONS

  • Power supply: Electronic auto-ranging
  • Input voltage range: 100-240 V, 50/60 Hz
  • Power consumption: 35 W at 230V / 50 Hz
  • Power in/out connector: Neutrik powerCON TRUE1 in/out
  • DMX and RDM data in/out: Locking 5-pin XLR
  • Camera output: RJ 45

• APPROVALS

  • CE Compliant
  • cETLus Compliant (pending)

• MECHANICAL SPECIFICATION

  • Height: 385 mm (15.2")
  • Width: 276 mm (10.9")
  • Depth: 147 mm (5.8")
  • Weight: 5.7 kg (12.6 lbs)

• RIGGING

  • Mounting positions: Horizontally or vertically
  • 1x Omega adaptor with ¼-turn quick locks
  • Universal operating position
  • Mounting points: 1 pair of ¼ -turn locking points
  • Safety cable attachment point

• INCLUDED ITEMS

  • User Manual
  • Universal Base Adaptor
  • Power cord including powerCON TRUE1 In connector

• ACCESSORIES

  • Wireless DMX external module: 10980127
  • Trigger Clamp Doughty: 17030386
  • Safety wire 35 kg: 99011963
  • Daisy Chain powerCON TRUE1 In/Out, EU, 2m, Indoor: 13052439
  • Daisy Chain powerCON TRUE1 In/Out, EU, 5m, Indoor: 13052444

• LEGAL

  • RoboSpot™ is a trademark of Robe lighting s.r.o.
  • RoboSpot™ MotionCamera is patented by Robe lighting s. r. o. and is protected by one or more pending or issued patents
