Ayrton Digital Lighting
Ayrton Khamsin-S LED Profile
Ayrton Digital Lighting
Ayrton Khamsin-S LED Profile
$7,895
In Stock and ready to ship in the U.S.
Under 1 Year Old
Ships in Cardboard
Cases Available for Additional Cost
Depot Warranty: 60-Day Depot Warranty
Condition: Excellent
Ships from: United States
People who were interested in this product also liked:
Downloads
Shipping
Used Sales This equipment has been inspected by a Main Light certified technician at one of our locations.
01
Features
- Compact design with 750W LED module
- Up to 40,000 lumens output (Khamsin-S) and native CRI greater than 90 (Khamsin-TC)
- Redesigned internal structure with cast aluminum sides
- Efficient cooling system
- Double rotating gobo wheel for morphing effects
- 8:1 zoom ratio and 7° to 58° beam aperture
- CMY color mixing system
- Framing section with 4 shutter blades
- Two wheels with six interchangeable HD glass gobos
- Effects section including continuous dynamic effects wheel, 15-blade iris diaphragm, and two frost filters
- Two rotating prisms (5-facet circular and 4-facet linear)
02
Specifications
- 13 elements 8:1 zoom high-resolution optic system
- 158 mm frontal lens
- Khamsin-S: 60,000 lumens 8000 K white light engine, output up to 40,000 lumens, 7000 K color temperature, CRI greater than 70
- Khamsin-TC: 48,000 lumens 7000 K white light engine, output up to 31,000 lumens, 6400 K color temperature, CRI greater than 90
- Rated life (L70): up to 40,000 hours
- Movement: 540° (pan), 262° (tilt)
- CMY color mixing, variable CTO, and fixed color wheel with six complementary colors
- 4 individually positionable shutter blades, rotation +/- 45°
- Iris diaphragm range: 15% to 100% open
- 2 frost filters: one light, one heavy
- 2 indexable rotating gobo wheels with 6 high-precision glass gobos, plus open position
- Electronic dimmer (0 to 100%), strobe effect (1 to 25 flashes per second)
- DMX 512 protocol, RDM compatible, stand-alone and Master/Slave modes, ArtNet™ & sACN protocol
- Power supply: 120 to 240 Volts, 50/60 Hz, maximum 1,150 W
- Advanced liquid cooling system, selectable ventilation modes, IP20 protection rating
- Housing: aluminum and steel skeleton, die-cast aluminum base, fire retardant ABS PC covers
- Installation: Omega brackets, mounting points, safety cable attachment point
- Operating temperature range: -10 °C (14 °F) to 45 °C (113 °F)
- Compliance: EU (EMC & LVD) and US (Safety & EMC)
- Dimensions: 494 x 778 x 280 mm (l x h x d)
- Weight: 39.8 kg
